Quick Turn Two Sided Smd Prototype Turnkey PCB Assembly Service Small Batch

Name: Quick Turn Two Sided Smd Prototype Turnkey PCB Assembly Service Small Batch
Brand: FASTPCBA
Price: 1 USD

Quick Turn Two Sided Smd Prototype Turnkey PCB Assembly Service Small Batch Manufactures

Brand Name : FASTPCBA

Model Number : Multilayer PCBs Assembly

Certification : IATF16949, ISO13485, ISO9001

Place of Origin : China

MOQ : 1pcs

Price : 1-20

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 150000 Pieces per Month

Delivery Time : 5

Packaging Details : PCB: Vacuum Packing/ PCBA: ESD Packing

Name : Quick Turn Two Sided Smd Prototype Turnkey PCB Assembly Service Small Batch

Keyword : Electronics Assembly Services

Number of layers : 1-48

PCBA Testing : X-ray,AOI Test,Functional test

Max size of finish board : 700*460mm

PCB outline : Square,circle,irregular(with jigs)

Min space : 0.075mm

Min line : 0.075mm

Surface Treatment : HASL, HASL Lead Free, Immersion Gold, Immersion Tin, Immersion Silver, Hard Gold, Flash Gold, OPS…

ROHS : CANEC1308721101

Process Characteristics : HDI Blind Buried Hole Process, High BGA Density, Small Hole-To-Line Spacing

Solder mask : Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue

Acceptable File Format : Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000

Contact Now

Quick Turn Printed Double Sided Boards Custom Made Circuit PCB Boards

Main Products Application:

* Household Appliances

* Medical Products

* Automotive Products

* Industrial Products

* Communication Products(AVL/GPS/GSM Devices)

* Consumer Electronics.

Product parameters:

Description	Capability
Laminate materials	FR4, High TG FR4, High Frequency, Alum, FPC...
Number of layers	1-48
Min.thickness for inner layers (Cu thickness are excluded)	0.003”(0.07mm)
Standard	(0.1-4mm±10%)
Board Thickness	Single/Double:0.008±0.004”
	4layer:0.01±0.008”
	8layer:0.01±0.008”
Bow and twist	no more than 7/1000
Outer Cu weight	0.5-4 0z
Inner Cu weight	0.5-3 0z
Min size	0.0078”(0.2mm)
Drill deviation	±0.002″(0.05mm)
PTH hole tolerance	±0.002″(0.005mm)
NPTH hole tolerance	±0.002″(0.005mm)
Color	Green,white,black,red,blue…
Min solder mask clearanace	0.003″(0.07mm)
Solder Mask Thickness	(0.012*0.017mm)
Silkscreen Color	white,black,yellow,blue…
Silkscreen Min size	0.006″(0.15mm)
Max Size of Finish Board	700*460mm
Surface Finish	HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline	Square,circle,irregular(with jigs)
Package	QFN,BGA,SSOP,PLCC,LGA

Delivery time for PCB
Layer	Prototype		Mass Productions (above 30 m2 )
Layer	Quick Turn	Unual Time	Mass Productions (above 30 m2 )
2	24 hours	3-4 days	8-10 days
4	48 hours	5-6 days	10-12 days
6	72 hours	6-8 days	12-14 days
8	96 hours	8-10 days	14-16 days
10	120 hours	12-14 days	16-18 days
...	...	...	...

Delivery Time for PCBA
Order Conditions	Standard Delivery Date	The fastest Delivery Date
Prototype (<20 pcs)	2 days	8 hours
Small Volum (20-100 pcs)	3 days	12 hours
Medium Volum(100-1000 pcs)	6 days	24 hours
Mass productions (>1000 pcs)	Depends on BOM	Depends on BOM

Quick Turn Two Sided Smd Prototype Turnkey PCB Assembly Service Small Batch

FASTPCBA is a one-stop comprehensive PCB manufacturing and assembly manufacturer of high-precision large, medium and small batch printed circuit board, and electronic component procurement.

Quick Turn Two Sided Smd Prototype Turnkey PCB Assembly Service Small Batch

FASTPCBA relies on the MY500 solder paste printer imported from Sweden, which can realize fast turnover line, no stencil solder paste printing, and fast delivery within 4 hours. MYDATA Sweden’s fully automatic SMT production line, with a daily production capacibility of 3 million points plus top-level quality control and testing equipment, controlled strictly by 9 “testing procedures”, high standards of anti-static, 5,000 square meters of dust-free production workshops, strictly implemented IATF 16949 / ISO13485 quality system standard, and obtained ISO9001-2016 quality management system certification, and to be a socially responsible company for customers, employees.
