Fr4 Rohs 94v0 Smt PCBA Production Multilayer Printed Circuit Board Assembly
Our advantages
FASTPCBA offers low to medium volume, high mix, PCBA services and end-to-end integration services for medical, automotive, millitary, aviation & aerospace, industrial. FASTPCBA with exceptional turnkey manufacturing services, we are able to produce and fully integrate PCB assemblies for OEMs seeking a one-stop PCBA manufacturing solution.
1. High-end, Small volume and Various kinds of PCB and PCBA service offered.
2. Speedy, Flexible and one-stop service in pcb manufacturing and pcb assembly.
3. Assembly and Purchasing service offere or their pointed agents.
4. Transparent quotation,cost and benefit are detailedly opened to customer.
5. With professional Engineers and Long-term successful experience in cooperating with customers inland and overseas, all new projects can be developed faster and better than expected.
6. With USA or Japan imported tin cream and tin bar, and 100% AOI testing during production, all PCBAs we made are more reliable.
PCB / PCBA Services
1. Test: ICT and functional with full tech and engineering support staff
2. FR-4, FR-4 High TG, CEM-1, CEM-3, Aluminum base material.
3. Single-sided PCB, double-sided PCB, multi-layer PCB, competitive price, good quality and good service.
4. Prototype qualifications through production volumes
5. HAL, HAL lead free, Immersion Gold/ Silver/Tin, OSP surface treatment.
6. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.
7. Quantities range from prototype to medium and batch production.
PCB Capacity
| Items | PCB capacity |
| Product name | SMT circuit board manufacturer custom electronic assembly pcb pcba |
| Material | FR-4; High TG FR-4; Aluminum; CEM-1; CEM-3; Rogers, etc |
| PCB type | Rigid, flexible, rigid-flexible |
| Layer NO. | 1, 2, 4, 6, up to 48 layer |
| Shape | Rectangular, round, slots, cutouts, complex, irregular |
| Max PCB dimensions | 700mm*560mm |
| Board Thickness | 0.2mm-4mm |
| Thickness Tolerance | ±10% |
| Min Hole Size | 0.1mm (4 mil) |
| Copper Thickness | 0.5 OZ-3OZ (18 um-385 um) |
| Copper Plating hole | 18um-30um |
| Min Trace Width | 0.075mm (3mil) |
| Min Space Width | 0.1mm (4 mil) |
| Surface finish | HASL, LF HASL, Imm Gold, Imm Silver, OSP etc |
| Solder mask | Green, red, white, yellow, blue, black, orange, purple |
PCBA Capacity
| Items | PCBA capacity |
| Product name | SMT circuit board manufacturer custom electronic assembly pcb pcba |
| Assembly details | SMT and Thru-hole, ISO SMT and DIP lines |
| Testing on products | Testing jig/mold , X-ray Inspection, AOI Test, Functional test |
| Quantity | Min quantity : 1pcs. Prototype, small order, mass order, all OK |
| Files needed | PCB : Gerber files(CAM, PCB, PCBDOC) |
| Components : Bill of Materials(BOM list) |
| Assembly : Pick-N-Place file |
| PCB Panel Size | Min size : 0.25*0.25 inches(6*6mm) |
| Max size : 1200*600mm |
| Components details | Passive Down to 0201 size |
| BGA and VFBGA |
| Leadless Chip Carriers/CSP |
| Double-sided SMT Assembly |
| Fine BGA Pitch to 0.2mm(8mil) |
| BGA Repair and Reball |
| Part Removal and Replacement |
| Component package | Cut Tape, Tube, Reels, Loose Parts |
| PCB+ assembly process | Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity |
FAQ :
Q: What service do you have?
FASTPCBA: We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and other value-added service.
Q: What is needed for PCB & PCBA quotation?
FASTPCBA: For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
For PCBA: PCB information, BOM,Testing documents.
Q: How to keep our product information and design file secret ?
FASTPCBA: We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
Q: What are the main products of your PCB/PCBA services?
FASTPCBA: Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.
Q: What is your minimum order quantity (MOQ)?
FASTPCBA: Our MOQ is 1 PCS, sample and mass production all can support.
Q: Are you factory?
FASTPCBA: Our factory is located in 1st Building, No. 18-1, Yuquan East Road, Yulv Village, Gongming Street, Guangming New District shenzhen, china.
We offer instant quotes for your turnkey PCB assembly order and you don’t need to wait for long to know how much the order would cost. Also, you can see the real-time status of your project. This helps you to monitor the PCB manufacturing stage. With a single point of contact, and flexible services, FASTPCBA’s full turnkey electronics assembly meets the unique needs of small businesses, large corporations, and entrepreneurs. You can upload your GERBER & BOM to receive a quote.
